Description

LOA 69.9 m
Beam 16.6 m
Draft 5.8 m

Built in year 2011
Class : American Bureau of Shipping
Flag : Mexico
Gross Tonnage of 2,501 and Nett Tonnage of 750

Dynamic Positioning of class : DP 2
Free Deck area about 550m²
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 2 tons
Deadweight : 3,011 metric tonnes
Capable of supplies of 760m³ Fuel Oils, 515m³ FW, 150m³ Brine and 245m³ Dry bulk

4 cabins with 1 berth
6 cabins with 2 berths
11 cabins with 4 berths

Speed : 12.5 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3516B-HD, 3,840 kw, 1,600 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 1 Caterpillar 95 kw, Bowthruster + Sternthruster (2 Bow 8T Kawasaki KT-72B3 CPP + 1 Stern 8T Kawasaki KT-72B3 CPP)

Specifications

Engine(s)

2 x 3,840 kw, 1,600 rpm, Caterpillar / Caterpillar Inc 3516B-HD,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
