Description

LOA 74.1 m
Beam 17 m
Draft 6.2 m
Bollard Pull : 150 tons

Free Deck area about 500m²
Capable of supplies of 720m³ Fuel Oils, 600m³ FW, 570m³ Liquid Mud and 230m³ Dry bulk
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 1.5 tons

Class : DNV
Gross Tonnage of 2,924 and Nett Tonnage of 878

Deadweight : 2,500 metric tonnes

Total passenger capacity 40

Speed : 15 knots
Engines : 2 x MaK 9M 32C- 4 Stroke, 4,500 kw, 600 rpm, Propellers 2 Controllable Pitch
Auxiliaries Engines : Bowthruster + Sternthruster (2 Bow 600kw SCHORCH 2 x 600 kW EI-driven CP FWD.)

Specifications

Engine(s)

2 x 4,500 kw, 600 rpm, MaK 9M 32C- 4 Stroke,
Propellers: 2 Controllable Pitch

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.

Location Map
